P235GH is a European standard pressure vessel steel grade. It is a non-alloy steel with specified elevated temperature properties, which means it is suitable for use in high-temperature applications such as boilers, pressure vessels, and heat exchangers.
The “P” in P235GH stands for “pressure,” and the number “235” refers to the minimum yield strength of the steel in megapascals (MPa). The “GH” suffix indicates that the steel is suitable for elevated temperature service.
P235GH is commonly used in industries such as oil and gas, chemical processing, and power generation. It is also used in the manufacturing of heat exchangers, steam boilers, and pressure vessels. P235GH is known for its excellent weldability and formability, making it a popular choice for fabrication and construction projects.
The chemical composition of P235GH is as follows:
– Carbon (C): 0.16% max
– Manganese (Mn): 0.60-1.20%
– Phosphorus (P): 0.025% max
– Sulfur (S): 0.015% max
– Silicon (Si): 0.35% max
– Nickel (Ni): 0.30% max
– Chromium (Cr): 0.30% max
– Molybdenum (Mo): 0.08% max
– Copper (Cu): 0.30% max
– Nitrogen (N): 0.012% max
– Aluminum (Al): 0.020% max
The composition may vary slightly depending on the manufacturing process and the specific requirements of the application. However, these are the typical chemical composition ranges for P235GH steel.
P235GH is a European standard pressure vessel steel grade. It is a non-alloy steel with specified elevated temperature properties, which means it is suitable for use in high-temperature applications such as boilers, pressure vessels, and heat exchangers.
The “P” in P235GH stands for “pressure,” and the number “235” refers to the minimum yield strength of the steel in megapascals (MPa). The “GH” suffix indicates that the steel is suitable for elevated temperature service.
P235GH is commonly used in industries such as oil and gas, chemical processing, and power generation. It is also used in the manufacturing of heat exchangers, steam boilers, and pressure vessels. P235GH is known for its excellent weldability and formability, making it a popular choice for fabrication and construction projects.
P235GH is a non-alloy steel that is suitable for use in high-temperature applications due to its elevated temperature properties, which include:
1. High temperature strength: P235GH has a minimum yield strength of 235 MPa, which makes it strong enough to withstand high pressure and temperature.
2. Good weldability: P235GH has good welding properties, which means it can be easily welded using common welding methods.
3. Excellent formability: P235GH has good formability, which means it can be easily shaped and formed without cracking or breaking.
4. Resistance to high-temperature corrosion: P235GH has good resistance to high-temperature corrosion, which means it can withstand the corrosive effects of steam, gas, and other high-temperature fluids.
Overall, the properties of P235GH make it a popular choice for use in high-temperature applications such as boilers, pressure vessels, and heat exchangers, where it is necessary to withstand high temperatures and pressures.
