| Standard: | PVC-Lined Steel Pipe | Grade Gruop: | 10#-45#, A53-A369 |
|---|---|---|---|
| Thickness: | 4 – 18 Mm, 4-18mm | Out Diameter: | 355.6-1229mm |
| Surface: | PE/2PE/3PE | Keyword: | Epoxy |
| Usage: | Water Supplies | Production Year: | Made By Lining |
| Product Name: | +RURY +KOTŁOWE | ||
| High Light: |
coated steel tube
Table of Content
隐藏
, epoxy coated gas pipe |
||
Product Name : SZIGETELT, BEVONATOS CSÖVEK, KORRÓZIÓVÉDELEM +RURY +KOTŁOWE
A hagyományos tűzihorganyzás, festés mellett, különösen nagy átmérőjű csöveknél (hegesztett és varratnélküli kivitel
esetén is) lehetőség van különböző külső és/vagy belső bevonatok megrendelésére.
Szigetelési, bevonatolási mérettartomány: Ø 21,3 – 1219,2 mm
Szigetelés típusok:
KÜLSŐ: 3LPE DIN 30670 szerint (PE poliethylén), 3LPP DIN 30678 szerint (polypropilén), vegyes polyetilén és polypropilén
szigetelés ISO/DIS 21809-1 szerint, egy vagy többrétegű epoxy szigetelés FBE, DIN 30671, PN-EN ISO 21809-1,
CAN/CSA-Z245.20 szerint, kettős fuziós kötésű epoxy bevonat DFBE, PN-EN ISO 21809-1, CAN/CSA-Z5245.20 szerint
BELSŐ: belső epoxy szigetelés API RP 5L2, PN-EN 10301 szerint
További lehetőségek:
KÜLSŐ: polyolefin, bitumen (aszfalt), cement vagy beton, kátrány bevonatok
BELSŐ: epoxy, polyamide, cement, beton bevonatok
ISOLATED, COATED TUBES, ANTI CORROSION
Interval: Ø 21,3 – 1219,2 mm
Coating types: OUTSIDE: polyetilen PE acc. To 3LPE DIN 30670, polypropilen acc. To 3LPP DIN 30678, mixed polyetilen
and polypropilen acc. To ISO/DIS 21809-1 , one or two, three layer epoxy coating acc. To FBE, DIN 30671, PN-EN ISO
21809-1, CAN/CSA-Z245.20
INSIDE: epoxy coating acc. To API RP 5L2, PN-EN 10301
Other possibilities:
Outside: polyfelin, bitumen,(asphalt), cement, concrete, tar coatings
Internal: epoxy, polamide, cement, concrete coatings
Polyethylene coating ø 159 – 820 mm +RURY +KOTŁOWE
The installed line makes possible to coat pipes in the O.D. range 159 – 820 mm with the three-layer coating pursuant to the DIN 30 670 Standard in normal design (maximum operating temperature 50°C)
or in special design (operating temperature 80/90°C, increased surface hardness). Thus, it covers the entire assortment of the spiral welded pipes, part of the seamless tube assortment, and leaves the space for coating of pipes, supplied by other manufacturers
Types and Features of Corrosion-resistant Steel Pipe +RURY +KOTŁOWE
| Product name | Features |
| Carbon Steel Pipe for Plumbing (“White Tube”) | This steel pipe, which is galvanized both inside and outside, offers outstanding workability. |
| Galvanized Steel Pipe for Water Piping (SGPW) | This steel pipe, which is thickly galvanized both inside and outside, offers outstanding workability. |
| PFP (Polyethylene-Lined Steel Pipe for Water Supplies) | This corrosion-resistant steel pipe for water supplies is coated on the inside with powdered polyethylene (PE). It boasts excellent quality, hygiene, and corrosion-resistance. It can be used for thread rolling. |
| JLP (PVC-Lined Steel Pipe for Water Supplies) | This corrosion-resistant steel pipe for water supplies is made by lining the inside of steel pipe with PVC pipe using a bonding agent. It is ideal for applications that require a high level of corrosion protection. |
| JDLP (PVC-Lined Steel Pipe for Building Wastewater Services) | This is lightweight steel pipe lined with PVC to address the need for more flexible and lighter structures as a result of the diversification of wastewater services and the increasing height of high-rise buildings. These products are compatible with WSP-042 (PVC-Lined Steel Pipe for Wastewater). |
| PLP-P2S (Polyethylene-Coated Steel Pipe) | The outside of this corrosion-resistant steel pipe for underground piping is seamlessly coated with polyethylene resin by extrusion, to achieve a high degree of corrosion-resistance. Compatible with JIS G 3469 P2S. |
| PLP-P1H (Single-Layer Bonded Polyethylene-Coated Steel Pipe) | This single-layer bonded polyethylene-coated steel pipe is made by strongly bonding a polyethylene coating onto steel pipe. It is suitable for laying underground and is compatible with JIS G 3469 P1H. |
| PLS (Small-Diameter Single-Layer Bonded Polyethylene-Coated Steel Pipe) | This small-diameter single-layer bonded polyethylene-coated steel pipe retains the corrosion-resistance of PLP and can be used with its coating for thread cutting and thread rolling. Compatible with JIS G 3469 P1H. |
| PLV (PVC-Coated Steel Pipe) | This is an integrally molded product made by strongly bonding PVC to steel pipe. It can be used for cutting and thread cutting without the coating peeling off and is also suitable for thread rolling. The use of highly weather-resistant PVC enables use for both underground and exposed piping. |
| Fire-Fighting Pipe VS (Exterior PVC-Coated Steel Pipe for Fire Fighting) | Fire-Fighting Pipe VS conforms to WSP-041 (Exterior PVC-Coated Steel Pipe for Fire Fighting). It is used for buried fire-fighting water pipe and interconnected water piping. |
Coated Pipes
Pipeline coating is the most consistent and successful solution for protecting ERW/Seamless pipes from corrosion, from moisture, other harmful chemicals.
Coated pipes are the most viable cost effective products used for transmission of oil, gas, water and other fluids. The coating provides pipelines with a constant protective layer that shield the pipes from any damaging effects of corrosion.
Coated pipes offer high resistance to corrosion on pipes and provide many benefits such as:
1. Increased Flow Capacity – A coating on pipes helps provide a smoother surface thus improving gas and liquid flow within pipes.
2. Reduced Cost – The pipeline coating increases the pipes durability so they can be deployed with minimum maintenance cost even in the harshest environments.
3. Lower energy usage – Various studies have shown that pipelines that are internally coated use less energy for pumping and compression of products through pipes. This helps in increased saving over time.
4. Clean delivery of products – The inhibitors used for the protection products can also be minimised by the use of coated pipes for delivery of products.
Thus, coating of pipelines can help you in reducing your maintenance cost and at the same time providing a corrosion free reliable protection.
Types of Coating
- 3 LPE (External 3 Layer Polyethylene)-link
- 3 LPP (External 3 Layer Polypropylene)-link
- FBE (External Fusion Bonded Epoxy (Single / Dual Layer))-link
- Internal Epoxy Coating-link
